Remote Controller


Suggested retail price

• 7” touch-panel LCD for PTZ and CCU functions
• Professional zoom lever for smooth, variable speed zoom control
• Heavy duty control lever for precise pan/tilt control
• Focus dial with push-auto function
• User assignable function keys
• IP control of up to 100 cameras
• Tally Input/Output (D-Sub)

Remote Controller
General Power requirement DC12V ( AC adapter )
Power consumption 0.6A (AC adapter)
Dimensions (WxHxD) 350 (W) x 110 (H) x 182 (D) mm
Weight approx. 2.1 kg
Operating temperature 0°C ~ 40°C (32°F ~ 104°F)
Operating humidity 20% to 90% (No dew)
Camera Supported Camera KY-PZ100
IP Control Max. 100 cameras
Preset Position Max. 100 positions
Protocol IPv4
LCD Touch Panel Supported
Assignable Functions Rotary Switch F1/F2 WB R/B, AE level, Speed (PAN/TILT), Shutter, Gain, Iris, Focus, Detail
Control Lever F3 Zoom, Iris, Focus, No function
USER Button (USER 1/USER 2) Exposure (AUTO/Shutter/Iris/MANUAL) White Balance (FAW/AWB/3200K/5600K/MANUAL) AWB TRIGGER, Focus (AUTO/MANUAL), Streaming, REC
Interface Power Input DC 12V (Exclusively Supplied AC adapter)
Tally D-Sub 9pin Input/Output: 3pin/5pin, 4pin/4pin, 5pin/3pin, Variable
LAN Terminal 10BASE-T/100BASE-TX
Accessories Supplied Accesories AC adapter, Wire clamp, Screw (M3), Instruction manual
