2 Megapixel 21.3" Color Display


Suggested retail price
  • 2 Megapixel 21.3" TFT color active matrix IPS technology
  • 16 Bit LUT
  • Luminance Stabilizing System
  • Uniformity Equalizer
  • Dicom Conformance Check
2 Megapixel 21.3" Color Display
Technology 21.3-inch, TFT color active matrix IPS technology
Display Area 432mm x 324mm
Pixel Pitch 0.27mm x 0.27mm
Contrast Ratio 1400:1 (typ)
Maximum Luminance 900 cd/m2 (typ)
Viewing Angle 176° Vertical and Horizontal
Native Resolution 1200 x 1600
Display Colors 16.77 million colors from a palette of 68 billion colors *1.06 billion colors with Display Port and 10-bit viewer
Input Signal DVI-D (1.0 compliant), Display Port (1.1a compliant)
Plug and Play DDC2B compliant
Input Power Supply 100V-240V, 50/60Hz
Maximum Power Consumption 75W
Calibration Control Luminance, Gamma, Capability of saving 3 sets of LUT settings (An optional calibration kit is required)
OSD Information Display Model name, Serial No., Total operating time, Calibration settings (Operating time since from last calibration, Luminance, Gamma), Current luminance and ambient light, DICOM conformance
USB Hub USB Rev. 2.0 compliant, Self-powered USB upstream connector (x1), USB downstream connector (x2)
Others Features Luminance and color uniformity correction, Hardware pivot, LED indicator, Multiple LUT, Self DICOM check function
Dimensions (WxHxD) Landscape 474mm x 468.4/529.9mm x 220mm
Portrait 367mm x 521.9/583.4mm x 220mm
Net Weight approx. 12kg
Mount Vesa mounting 100mm x 100mm
Accessories Power cord, DVI cable, Display port cable, USB cable, Users manual
